High Carbon Steel Wire Rope

High Carbon Steel Wire Rope

Using high-quality high carbon steel wire rods, refined through advanced cold drawing, twisting, and rope joining processes, our steel wire ropes exhibit excellent mechanical performance and long service life under harsh working conditions.

Features



product presentation



Using high-quality high carbon steel wire rods, refined through advanced cold drawing, twisting, and rope joining processes, our steel wire ropes exhibit excellent mechanical performance and long service life under harsh working conditions.





core advantage ​

 ​

1

Excellent strength and load-bearing capacity:

-The high carbon steel material endows the steel wire rope with extremely high tensile strength and breaking force, which can safely withstand heavy loads and meet the requirements of high-strength operations.

2

Excellent wear resistance and fatigue resistance:

-The surface of the specially treated steel wire is smooth and hard, significantly reducing friction loss, effectively resisting repeated bending and wear, extending service life, reducing replacement frequency and overall cost.

3

Excellent resilience and flexibility:

-The optimized twisting process ensures that the steel wire rope maintains high strength while having good flexibility and impact resistance, adapting to complex operating trajectories and dynamic loads.

4

High dimensional accuracy and structural stability:

-Strict production control ensures that the diameter tolerance of the steel wire rope is small, the structure is tight and uniform, the operation is smooth and stable, vibration and deformation are reduced, and operational safety and efficiency are improved.

5

Flexible customized services:

-Support on-demand customization of diameter, structure (such as 6x19, 6x37, 7x7, 7x19, etc.), length, twist direction (left twist/right twist), and surface treatment methods to meet specific requirements of different application scenarios.5



application area ​



Manufacturing and heavy industry

Factory cranes, lifting equipment, production line traction, metallurgical equipment.

Agriculture, forestry, animal husbandry, and fishery

Logging equipment, agricultural machinery traction, and fishing net support.

Energy and electricity

Wind turbine cables, transmission line supports, drilling platform mooring.

Transportation

Cable car cable car, elevator balance rope, car trailer rope.





technical specifications



Parameter

Standard

Grade

70#, 72A, 72B, 80#, 82B

Tensile strength grade

1570 MPa, 1670 MPa, 1770 MPa, 1870 MPa, 1960 MPa and higher grades.

Rope core

Fiber core , independent steel wire rope core , strand core, etc

Structure

6x7, 6x19S, 6x19W, 6x36WS, 6x37, 7x7, 7x19, 8x19S, 18x7, 19x7, 35Wx7, etc.

Surface Treatment

Bright/Galvanized/PVC Coated, PE Coated

Twist direction

RHOL/LHOL/RHL/LHL/RHOL

Execution standards

ISO 2408, DIN 3052, EN 12385, BS 302, ASTM A1023/A1023M, GB 8918
