Brass Coated Steel Wire
As the core material in the field of hose reinforcement, brass coated steel wire stands out with its superior performance, making it the preferred choice for high-pressure hose reinforcement layers. Our brass coated steel wire relies on advanced plating processes and high-precision drawing techniques, seamlessly integrating the high-strength characteristics of high-carbon steel with the excellent adhesion of brass plating.
Features
product presentation
As the core material in the field of hose reinforcement, brass coated steel wire stands out with its superior performance, making it the preferred choice for high-pressure hose reinforcement layers. Our brass coated steel wire relies on advanced plating processes and high-precision drawing techniques, seamlessly integrating the high-strength characteristics of high-carbon steel with the excellent adhesion of brass plating. It not only boasts outstanding tensile strength, flexibility, and corrosion resistance but also significantly enhances the overall performance and service life of hoses through its strong bond with rubber. Specifically designed for high-pressure and highly corrosive applications in hydraulic, oil, and chemical industries.
core advantage
Excellent corrosion resistance, adapt to harsh environment
The dense and uniform brass coating is formed by precision electroplating process, which can effectively resist the erosion of water, oil, chemical media and salt spray. In extreme environments such as Marine engineering and chemical equipment, it can maintain stable performance for a long time, greatly prolong the service life of rubber hose and reduce maintenance costs.
Ultra-high strength and flexibility to cope with complex working conditions
High-quality high carbon steel is selected as the substrate, combined with advanced drawing process, so that the tensile strength of the product is up to 3500MPa, far exceeding the industry standard. At the same time, it maintains good flexibility, can easily adapt to complex bending and dynamic pressure environment, to ensure stable operation under high pressure, high frequency vibration and other harsh working conditions.
Super strong rubber bonding performance to ensure structural stability
The brass coating has unique surface activity, which forms high strength chemical bonding with natural rubber, nitrile rubber (NBR), EPDM (TPE) and other rubber materials, significantly enhancing the adhesion between steel wire and rubber layer, effectively avoiding interlayer peeling, and ensuring the integrity and safety of the hose structure.
Full specification customization service to meet diverse needs
We provide full specifications of products with diameter of 0.15mm-2.0mm and coating thickness of 0.5μm-5μm, and support personalized customization of tensile strength and surface treatment process. Whether it is conventional application or special requirements, we can respond quickly and provide precise matching solutions.
application area
Hydraulic hose field
It is widely used in high pressure hydraulic systems of construction machinery, mining equipment and agricultural machinery. It can effectively withstand pulse pressure and oil erosion to ensure the stable operation of hydraulic system and improve the reliability of equipment.
Oil hose sector
It is suitable for crude oil transportation, refining equipment, gas station oil pipes and other scenarios. With excellent anti-hydrogen sulfide corrosion and oil penetration performance, it can ensure the safety and efficiency of petroleum transportation process.
Pneumatic hose field
In the application of factory automation equipment and pneumatic tools, ensure the efficient and safe transmission of compressed air to help achieve the stable operation of automatic production.
Special hose field
For special requirements such as chemical conveying hose and high temperature steam hose, it can be adapted to special rubber materials such as EPDM and fluororubber, and play excellent performance under extreme conditions such as high corrosion and high temperature, to meet the demanding requirements of special industries.
technical specifications
|
parameter |
specifications |
standard |
|
Diameter range |
0.15mm - 2.0mm |
ASTM A370 / ISO 6892 |
|
tensile strength |
2000MPa - 3500MPa |
ISO 6892-1 |
|
Copper plating thickness |
0.5μm - 5μm |
ASTM B487 |
|
extensibility |
≥1% |
ISO 6892-1 |
|
Number of twists (360°) |
More than 20 times |
ASTM A938 |
|
Rubber bonding strength |
≥8N/mm |
ISO 4647 / ASTM D429 |
