Uncoated Steel Wire
As a master craftsman in the field of metal wire, we rely on advanced production processes and stringent quality control systems. Using high-quality carbon steel as the core material, we achieve mirror-like smooth surfaces and superior performance through cold drawing, precision heat treatment, and surface finishing techniques.
Features
product presentation
As a master craftsman in the field of metal wire, we rely on advanced production processes and stringent quality control systems. Using high-quality carbon steel as the core material, we achieve mirror-like smooth surfaces and superior performance through cold drawing, precision heat treatment, and surface finishing techniques. With a perfect balance of micron-level accuracy, high strength, and excellent ductility, as well as outstanding adaptability for subsequent processing, we provide stable and reliable material solutions for precision instruments, automotive manufacturing, construction engineering, and other fields.
Our uncoated steel wire is meticulously controlled at every stage of production through refined processes. By employing special stress-relief treatment and surface purification techniques, we not only endow the product with an exceptionally long fatigue life but also ensure that there are no residual oxide scales on the surface. This lays a solid foundation for subsequent deep processing steps such as plating, painting, and welding, truly achieving "one-time formation, endless possibilities."
core advantage
Mirror surface quality, define the precision benchmark
uncoated steel wire is produced using multi-stage cold drawing combined with precision polishing techniques, controlling surface roughness to ≤Ra 0.1 μm, achieving mirror-like smoothness. This extreme surface treatment significantly reduces friction coefficients, effectively minimizing operational wear, making it particularly suitable for high-precision transmission systems and sealing components where stringent surface quality requirements are essential. The uncoated bare wire design fundamentally avoids the risk of coating peeling, ensuring stability and reliability over long-term use.
Strong and resilient, carrying multiple demands
Selected from high-carbon steel, medium-carbon steel, and low-alloy steel materials, SWRH72A is processed through scientific composition ratios and heat treatment techniques to achieve a tensile strength range of 800MPa to 2200MPa, accurately matching various load conditions. At the same time, it maintains an elongation rate of ≥6%, ensuring moderate ductility while maintaining rigidity. Combined with special stress-relief treatments, this endows the product with excellent fatigue resistance, significantly extending its service life and providing long-lasting stability for critical components.
Flexible customization service, rapid response and delivery
Providing full-diameter coverage from 0.2mm to 20mm, and supporting custom non-standard sections such as flat wires and hexagonal wires, to meet diverse product design requirements. We can offer differentiated process options like annealing and spheroidizing according to customer needs, enabling flexible adjustments in product performance. Leveraging an efficient production management system and rapid response mechanisms, we guarantee sample delivery within 48 hours, providing efficient solutions for urgent projects and customized demands.
application area
Mechanical manufacturing
Uncoated steel wire is used in precision springs, bearing ball cage, hydraulic piston rod and other core components. With high precision surface and excellent mechanical properties, it improves the operation accuracy and reliability of equipment.
Construction projects
Uncoated steel wire, as a key material for prestressed concrete steel wire, steel structure cable and wall reinforcement, enhances the stability of building structure with high strength and durability, and ensures the quality and safety of engineering.
Home hardware
Uncoated steel wire is used in high-grade furniture hinges, pull basket guide rails, bathroom accessories and other products, through smooth surface and good corrosion resistance, improve the beauty and service life of household products.
The automobile industry
It is suitable for clutch cable, brake system components, seat belt coil spring and other key parts of the car, providing reliable guarantee for driving safety with high tensile strength and fatigue resistance.
Electronic equipment
It is used for micro motor shaft, precision connection wire and 3C product structure parts to meet the strict requirements of the electronics industry on material precision, conductivity and stability.
Daily necessities
It can be used to make metal woven nets, gardening tools, handicraft frames, etc., with good molding and surface texture, taking into account both functionality and beauty.
technical specifications
|
parameter |
specifications |
|
material quality |
High carbon steel (SWRH72A/82B), medium carbon steel, low alloy steel |
|
Diameter range |
0.2mm-20mm (customizable for irregular sections) |
|
tensile strength |
800MPa-2200MPa (process adjustable) |
|
extensibility |
≥6% (GB/T 4357 standard) |
|
surface finish quality |
Ra ≤ 0.1 μm (optional mirror polishing) |
|
Straightness tolerance |
≤1mm/m (up to 0.5mm/m for high precision applications) |
|
approval standards |
ISO 9001, ASTM A510, JIS G3505 |
